Acoustic Magnetic System  9009 Contact system

Fashionable ABS eas anti-shoplifting system 58khz for first -class shopping mall
Product Description

AM (Acoustic Magnetic )Detector
Model No: AS-9001
Material
160* 430*35CM
SIZE
1600(H)*440(W) *40MM
Working Frequency
58KHZ
Working Style
Working with Host
Signal Processing Style
Digital Signal Processing
Detecting range

DR AM Soft label
0.6 *2 sides(0.18′ *2 sides)
AM Super hard tag
0.9’*2 Sides (0.27’*2 Sides )
Specification:

Detection area
More than 95%
Output :
24 DC ,100 Ma
Power
≤25W
Voltages
AC(50~60hz)110~230V ≤15W
Weight
16kg
Working Environment
20℃-45℃
Signal processing mode
Noopsyche DSP
Main Advantages:
Concealment: install antennas behind the door, good concealment
2. Function features of AS9009 Real Store EAS Security Antenna EAS AM 58Khz System for Clothing
1.Streamline: simple,elegant and strong design
2.Concealment: install antennas behind the door, good concealment
3.Stability: adopted software controlling technology, more stable and low fault alarm rate
4.Alarm rate:adopted DSP technology and high alarm rate
5.Operation:Integrated controller and antenna, simple operation
6.Installation ways: embedded, cutting, trunking
3. Technology features of N-2688C Real Store EAS Security Antenna EAS AM 58Khz System for Clothing
Frequency: 58KHZ
Input voltage: 220VAC ± 10% 50Hz
Working voltage: 24VDC
Rated power:≤20W
Power fuse: 250V 1A
Alarm indication: acoustic-optic alarm
Terminal output: 24V 100mA
Signal processing mode: DSP
Producing technology: ISO 9001 inspection and low carbon
Sync interface:yes
Detection width(each side): soft label: ≤0.7M
Hard tag with 25-39mm magnetic bar inside:≤1.1M
Hard tag with 39-50mm magnetic bar inside:≤1.2M
4. Description of AS9009 Real Store EAS Security Antenna EAS AM 58Khz System for Clothing

Adopted PVC raw material,integrated controller and antenna, simple installation and adjustment, designed specially for brand

stores eg. Clothes shop, shoe & hat, sports goods, passed European Union CE standard and National Quality Inspection Center

and exported to over 60 countries.
5. Details of AS-9001 Real Store EAS Security Antenna EAS AM 58Khz System for Clothing
